Showtec LAMPY 40 1U Lighting Controller

Description

Control Mode DMX, MIDI
DMX Channels 512

Patch mode Yes
Display LCD, Touch
Display Size 10.1 ”
External Display Yes
External Display Resolution (Horizontal) 1920
External Display Resolution (Vertical) 1080
Fixtures 512
Buttons 60
Cue Lists 90
Display Encoders 4
Display Encoder Type OLED
Encoder Wheels 4
Faders 41
OSC (Open Sound Control) Yes
Playback Buttons 40
Playback Faders 40
Playback Pages 9
sACN Optional
Art-Net Optional
SMPTE Timecode No
Effects Engine Yes
Universes 1
Power Supply 100-240 V AC 50/60 Hz
Power Consumption 60 W
Power Connector In Power Pro Blue
DMX Connector Out XLR 3P, XLR 5P
Data Connector In RJ45, USB
Data Connector Out RJ45, USB
MIDI Connector Yes
Ethernet Ports 1
Audio Triggers 3
Length 721 mm (28.386″)
Width 345 mm (13.583″)
Height 128 mm (5.039″)
Weight 11.8 kg (26.015 lb)
IP Rating IP20 (indoor use only)
Housing Metal, Plastic
Colour Black
Cooling Convection
LED Indicators
Operation mode, Output level, Output Level Mimic
Desk Light Built-in Worklight
Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Included Power Pro Cable
